Here's How To Install A Gate​ On An Existing Chain Link Fence

Whether you've bought a property with a fence or built a chain link fence DIY style, there may be a time when you need to add a new entryway to the barrier. Maybe you're dissatisfied with the gate's original location or simply need a second one to accommodate new traffic. In either case, don't worry too much; in most cases, adding a new gate to a chain link fence is a DIY task most homeowners can handle. And if you're concerned that the desired location of the gate is far from existing posts, let us set your mind at ease — you can add a gate anywhere along the fenceline if you know the proper installation steps.

Advertisement

There are three ways to add a new gate to an existing chain link fence. The least complicated method is to squeeze one between two existing fence posts. Since the posts are already in place, all you'll need to do is cut away the fencing material and hang the gate. The only complication is finding a gate that matches the post spacing. The second option is to hang the gate next to one post and install another. In this scenario, you'll need to drive a new post into the ground. Finally, the third option lets you hang a gate anywhere along the fence line, even if no posts are nearby. This option entails setting up two brand new fence posts for the gate. All three methods loosely apply to different types of fencing. Below, we'll walk you through the different ways of adding a new gate to your existing chain link fence.

Advertisement

Three ways to add a gate to an existing chain link fence

Regardless of where you're adding the gate, be sure to wear protective equipment. That's because the fence will lose its tightness as you start to disassemble it, and the motion of it springing back can pull your fingers with it or send bolts flying at a high speed. At the very least, wear goggles and gloves, and make sure nobody is in the vicinity when you start to loosen the chain link.

Advertisement

If you're lucky enough to have two existing posts that can hold the gate, take off the wires and rigging that holds the chain link material to the posts. Then, get rid of the top rail and any remaining bolts or bands. Finally, measure the resulting opening accurately from the inside of one post to the other and order a gate to fit. Some companies manufacture gates to custom sizes (these typically range up to 30 feet in width), and you may well have to use such a service if the opening doesn't accommodate a standard gate.

In case your preferred gate location is only close to one post, follow the same procedure as above and roll back the chain link material a sufficient distance to fit the new gate. Then hang the gate onto the existing post — this way, you'll know exactly where to situate the new post (i.e. at the other end of the gate). Finally, if you're fitting the gate in the middle of the fence line, you'll need to mark the locations of the posts and then cut back the chain link material between the markings. You must also cut the top rail away before setting in the new posts and hanging the gate. Be sure to make accurate measurements before cutting so you don't have to pay to repair your chain link fence after the gate addition.
